//////////////// alarm_data = 0x04 ////////////////
//////////////////////////////////////////////////////////////////////
//////////////////////////////////////////////////////////////////////
Min Flow Rate value
1.6. SETTING THE SLAVE ADDRESS
The Profibus address of the slave can be set with the converter keypad and the menu
7 - Communication --> Address
For the changing of address it’s not necessary to switch off the Flow meter by removing the power supply,
because the module detect when the address is changed it set the function Autoreset.
After the time of 5 seconds the slave module return in data exchange with the new address.
NOTE: For reasons of compatibility the menu Address of the Profibus is the same used for inserting the
address of the RS-485 communication channel of the Flow meter that can accept values in the range 000-
255, but the valid range for the Profibus Address is only 001, 002…126.
NOTE: The menu Communication is visible in the screen of the Flow meter only if the parameter RS 485 is
set ON in the menu 11-Internal Data.
1.7. BAUDRATES
The Baudrates supported are:
9.6 kBaud
19.2 kBaud
31.25 kBaud
45.45 kBaud
93.75 kBaud
187.5 kBaud
500 kBaud
1.5 MBaud
3 MBaud
6 MBaud
12 MBaud
The baudrate is automatically recognized by the slave module.
1.8. GSD FILE
The name of the GSD file is ME10034.GSD is included on the shipment packaging .
1.9. TERMINALS DESIGNATION AND CABLE CONNECTION
For the connection of the Profibus cable to the Flow meter see the section 1.1 Characteristics of the module.
Cable specification:
All cables used must meet the following parameters according to the PROFIBUS specification for copper
signal cable data wires.
