03 PROFIBUS DP MODULE- DATA LINK
DESCRIPTION
Document Data Date Date
File name ProfibusDP_emanual_Burkert_04.doc 19/03/08 19/03/08 19/03/08
6
-----------------------------------------
SlotDefinition
Slot(1) = "Process Data" 1
EndSlotDefinition
-----------------------------------------
The Configuration correspond to 8 bytes Input and the last byte indicate the Data Type selected .
Modifing the last byte in the GSD file it is possible to set the type of the Flow rate:
With the Configuration 0x41,0x0F,0x00 the Flow rate is in % ( 4 byte )
process flags ( 2 byte )
dynamic variations ( 1 byte )
Data Type = 0 ( 1 byte )
-----------------------------------------------------------
Number of Input byte exchanged ( 8 byte )
With the Configuration 0x41,0x0F,0x01 the Flow rate is in tecnical unit ( 4 byte )
process flags ( 2 byte )
dynamic variations ( 1 byte )
Data Type = 1 ( 1 byte )
-----------------------------------------------------------
Number of Input byte exchanged ( 8 byte )
With the Configuration 0x41,0x0F,0x02 totalizers positive ( 4 byte )
process flags ( 2 byte )
dynamic variations ( 1 byte )
Data Type = 1 ( 1 byte )
-----------------------------------------------------------
Number of Input byte exchanged ( 8 byte )
With the Configuration 0x41,0x0F,0x03 partial totalizers positive ( 4 byte )
process flags ( 2 byte )
dynamic variations ( 1 byte )
Data Type = 1 ( 1 byte )
-----------------------------------------------------------
Number of Input byte exchanged ( 8 byte )
With the Configuration 0x41,0x0F,0x04 totalizers negative ( 4 byte )
process flags ( 2 byte )
dynamic variations ( 1 byte )
Data Type = 1 ( 1 byte )
-----------------------------------------------------------
Number of Input byte exchanged ( 8 byte )
With the Configuration 0x41,0x0F,0x05 partial totalizers negative ( 4 byte )
process flags ( 2 byte )
dynamic variations ( 1 byte )
Data Type = 1 ( 1 byte )
-----------------------------------------------------------
Number of Input byte exchanged ( 8 byte )
