PROFIBUS DP MODULE- DATA LINK
DESCRIPTION
Document Data
Date
Date
File name
ProfibusDP_emanual_Burkert_04.doc
19/03/08 19/03/08 19/03/08
41
byte 0: (8 bits integer) INDEX Input: the value set the type of the Input data
byte 1: (8 bits integer) INDEX Output = 42(dec)
byte 2: (8 bits integer) menu Measure – cut-off es. 1(dec) / 10 = 0.1%, 255(dec) / 10 Æ 25.5%
byte 3: (8 bits integer) menu Batch - N.samples
byte 4: (8 bits integer) menu Batch – Diff.thr
bytes 6-7: (2 bytes 16 bit unsigned integer, MSB first) menu Batch – V.com (value expressed in the same
units and with the same decimal digits of the volume counters)
bytes 8-9: (2 bytes 16 bit unsigned integer, MSB first) menu Batch – V.pre (value expressed in the same
units and with the same decimal digits of the volume counters)
es.
Insertion of the parameters value:
byte 0: 0xXX index input
byte
1:
0x2A
=
42(dec) index output
byte
2:
0x01
Æ cut-off ( menu Measure ) = 0.1%
byte
3:
0x02
Æ N.samples ( menu Batch ) = 2
byte
4:
0x03
Æ Diff.thr ( menu Batch ) = 3%
byte 5: 0x00 Æ byte alignment
byte
6:
0x00
byte
7:
0x04
Æ V.com ( menu Batch ) = 00.004
byte
8:
0x00
byte
9:
0x05
Æ V.pre ( menu Batch ) = 00.005
-----------------------------------------------------------------------------------------------------------------------------
INDEX Output = 43(dec) Setting Batch Data and Batch Parameters with only this index
With this index it is possible to insert the batch data and batch parameters at the same time.
byte 0: (8 bits integer) INDEX Input: the value set the type of the Input data
byte 1: (8 bits integer) INDEX Output = 43(dec)
bytes 2-3: (2 bytes 16 bit unsigned integer, MSB first) number of batch processes done for this batch
memory.
bytes 4-5: (2 bytes 16 bit unsigned integer, MSB first) value of the safety batch timer expressed in tenths
of seconds.
bytes 6-9: (4 bytes 32 bits unsigned long integer, MSB first) batch quantity value expressed in the same
units and with the same decimal digits of the volume counters.
byte 10: (8 bits integer) menu Measure – cut-off es. 1(dec) / 10 = 0.1%, 255(dec) / 10 Æ 25.5%
byte 11: (8 bits integer) menu Batch - N.samples
byte 12: (8 bits integer) menu Batch – Diff.thr
bytes 14-15: (2 bytes 16 bit unsigned integer, MSB first) menu Batch – V.com (value expressed in the
same units and with the same decimal digits of the volume counters)
bytes 16-17: (2 bytes 16 bit unsigned integer, MSB first) menu Batch – V.pre (value expressed in the
same units and with the same decimal digits of the volume counters)
NOTE: The only recipe that is possible to use for this index INDEX Output = 43(dec) is the 00 in the
