Byte 2 = 0x08(hex) command for Reset the slave module. After 5 seconds the module return in the data
exchange.
Byte 2 = 0x32(hex) command for Autozero Calibration
Byte 2 = 0x60(hex) command for set the type of language in the meter ( Note: It is firstly necessary to
read the type of the language of the meter, for to set it with this command )
Byte 3 = type of language:
0x00 = 0(dec) = English
0x01 = 1(dec) = Italian
0x02 = 2(dec) = French
0x03 = 3(dec) = Spanish
es.
Reset Totalizers
byte 0: 0xXX = index input
byte 1: 0x0A = 10(dec) index output
byte 2: 0x06 Æ Command
-----------------------------------------------------------------------------------------------------------------------------
es.
Reading current type language of the Flow Meter
byte 0: 0x21 = 33(dec) index input Æ see INDEX Input = 33(dec)
byte 1: 0x0A = 10(dec) index output
byte 2: 0x07 Æ Command
-----------------------------------------------------------------------------------------------------------------------------
es.
Writing the type language in the Flow Meter after the firsly reading of the current language set in the meter
byte 0: 0x21 = 33(dec) index input Æ see INDEX Input = 33(dec)
byte 1: 0x0A = 10(dec) index output
byte 2: 0x60 = 96(dec) Command for set language
byte 3: 0x01 Æ set italian language in the meter
-----------------------------------------------------------------------------------------------------------------------------
es.
Set Autozero Calibration
byte 0: 0xXX = index input
