PROFIBUS DP MODULE- DATA LINK
DESCRIPTION
Document Data
Date
Date
File name
ProfibusDP_emanual_Burkert_04.doc
19/03/08 19/03/08 19/03/08
42
meter and the name utilized for this recipe is PROFIBUS.
es.
Insertion of the parameters value:
byte 0: 0xXX index input
byte
1:
0x2A
=
43(dec) index output
byte
2:
0x00
byte
3:
0x00
Æ 0(dec) value for reset the counter
byte
4:
0x00
byte
5:
0x0F
Æ 15 (dec) safety batch timer
byte
6:
0x00
byte
7:
0x00
byte
8:
0x00
byte
9:
0x01
Æ 1(dec) batch quantity
byte
10:
0x01
Æ cut-off ( menu Measure ) = 0.1%
byte
11:
0x02
Æ N.samples ( menu Batch ) = 2
byte
12:
0x03
Æ Diff.thr ( menu Batch ) = 3%
byte 13: 0x00 Æ byte alignment
byte 14: 0x00
byte
15:
0x04
Æ V.com ( menu Batch ) = 00.004
byte
16:
0x00
byte
17:
0x05
Æ V.pre ( menu Batch ) = 00.005
-----------------------------------------------------------------------------------------------------------------------------
3.1 DPV1 ACYCLIC DATA EXCHANGE
The software of the module implement the DP standard/DPV1 functionality for communication of the slave
with a Class 1 (parameterization) Master and a Class 2 Master.
With the Acyclic Service of data exchange and with the Acyclic Slot and Acyclic Index it is possible to
send and return configuration parameters from the Flow meter with a Class 1 (parameterization) Master and
a Class 2 Master.
For the communication with a Class C1 master the Slot is ignored.
Only Slot 0 is used for the Acyclic Service of data exchange for the comunication with a Class 2 master.
3.2 Acyclic Read Data from the Flow Meter
For return data with the Acyclic Read Service and a Class 1 Master the Acyclic Slot is ignored and every
value is not checked in the slave. The only value used for select the data is the Acyclic Index.
If the master is a Class 2 master, it is necessary insert the value of the Acyclic Slot = 0 and with the value
of the Acyclic Index there is the selection of the data returned.
Below there is the description list of the type of the bytes returned with the different value inserted in the
Acyclic Index.
