PROFIBUS DP MODULE- DATA LINK
DESCRIPTION
Document Data
Date
Date
File name
ProfibusDP_emanual_Burkert_04.doc
19/03/08 19/03/08 19/03/08
26
byte 1: 0x0A = 10(dec) index output
byte 2: 0x32 Æ Command
-----------------------------------------------------------------------------------------------------------------------------
INDEX Output = 20(dec) Setting Data and Time in the Flow Meter (only for ML 210)
byte 0: (8 bits integer) INDEX Input: the value set the type of the Input data
byte 1: (8 bits integer) INDEX Output = 20(dec)
byte 2-5: 32 bits long integer containing the date and time expressed in minutes starting from 01-01-1992
the most significant byte must be sent first.
INDEX Output = 40(dec) Batch Commands
For to use the batch function it is firstly necessary to set ON the menu Batch in the Flow Meter ( see the
Flow Meter Manual )
byte 0: (8 bits integer) INDEX Input: the value set the type of the Input data
byte 1: (8 bits integer) INDEX Output = 40(dec)
byte 2: (8 bits integer) batch Command
0x10(hex) Read the batch data memory, the data are returned with the INDEX Input = 40(dec)
byte 3: (8 bits integer) batch Code
Type of code that is possible to insert in the byte 3:
0x40(hex) = command for reading the recipe
0x12(hex) Set batch with the code in the byte 3
byte 3: (8 bits integer) batch Code
Type of command that is possible to insert in the byte 3:
0x01(hex) = command for reading the current batch status ( see INDEX Input = 40(dec) or
42(dec) for to read the status)
0x02(hex) = command for starting the current batch process
0x03(hex) = command for suspending the current batch process
0x04(hex) = command for resetting the current batch process
0x13(hex) Read the batch parameters, the data are returned with the INDEX Input = 42(dec)
es. Reading Batch Data:
byte 0: 0x28 = 40(dec) index input Æ see INDEX Input = 40(dec) Batch Data
byte
1:
0x28
=
40(dec) index output
byte
2:
0x10
Æ Command
byte
3:
0x40
Æ Code
-----------------------------------------------------------------------------------------------------------------------------
es. Reading Batch Parameters:
byte 0: 0x2A = 42(dec) index input Æ see INDEX Input = 40(dec) Batch Data
