PROFIBUS DP MODULE- DATA LINK
DESCRIPTION
Document Data
Date
Date
File name
ProfibusDP_emanual_Burkert_04.doc
19/03/08 19/03/08 19/03/08
39
bits 0..4 = number of the batch memory to be read (0..15)
bit 5 = must be set to zero
bit 6 = 1 if this batch memory must be set as active batch process, 0 if this batch memory is to be
read only.
bit 7 = must be set to zero
0x12(hex) Set batch with the code in the byte 3
byte 3: (8 bits integer) batch Code
Type of command that is possible to insert in the byte 3:
0x01(hex) = command for reading the current batch status ( see INDEX Input = 40(dec) or
42(dec) for to read the status)
0x02(hex) = command for starting the current batch process
0x03(hex) = command for suspending the current batch process
0x04(hex) = command for resetting the current batch process
0x13(hex) Read the batch parameters, the data are returned with the INDEX Input = 42(dec)
es. Reading Batch Data:
byte 0: 0x28 = 40(dec) index input Æ see INDEX Input = 40(dec) Batch Data
byte
1:
0x28
=
40(dec) index output
byte
2:
0x10
Æ Command
byte
3:
0x40
Æ Code for read the first recipe and set it as the current
----------------------------------------------------------------------------------------------------------------------------
es. Batch Commands:
byte 0: 0x28 = 40(dec) index input Æ see INDEX Input = 40(dec) Batch Data
byte
1:
0x28
=
40(dec) index output
byte
2:0x12
Æ Command
byte
3:0x01
Æ Code Read Status
0x02
Æ Code Start Batch
0x03
Æ Code Stop Batch
0x04
Æ Code Reset the current Batch process
----------------------------------------------------------------------------------------------------------------------------
es. Reading Batch Parameters:
byte 0: 0x2A = 42(dec) index input Æ see INDEX Input = 40(dec) Batch Data
byte
1:
0x28
=
40(dec) index output
byte
2:
0x13
Æ Command
----------------------------------------------------------------------------------------------------------------------------
INDEX Output = 41(dec) Setting Batch Data Memory
With this index it is possible to insert the batch data memory
