84
Acquiring Signals System
Shown below is the “ACQUIRE” button for entering the menu for
“Acquiring Signals”.
Table 28- Acquiring Signals Function Menu
When you acquire a signal, the oscilloscope converts it into a digital form
and displays a waveform. The acquisition mode defines how the signal is
digitized and the time base setting affects the time span and level of detail
in the acquisition.
Option Setting Introduction
Acquisition Sampling Use for sampling and accurately display
most of the waveform.
Peak Detect Detect the noise and decrease the
possibility of aliasing.
Average Use to reduce random or uncorrelated
noise in the signal display.
Averages
(4, 16, 32, 64,
128, 256)
Select number of averages.
Sinx/x On
off Use sin interpolation.
Use linear interpolation.
Mode Equ time
Real time Set the Sampling mode to Equ time.
Set the Sampling mode to Real time.
Sa Rate Display system sampling rate.
