129
Save Picture When the USB flash drive insert to the
USB Host interface (now the USB
flash drive open status icon displays on
the top of the screen), select “Save
picture” and press the “Save” knob to
go into the Save/Recall interface.
Save Go to the Save/Recall interface.
Figure 65 - Save Picture Screen
To save waveform image to USB flash drive, do the following:
1. Select the screen image that you want.
2. Press the “SAVE/RECALL” button to enter “SAVE/RECALL”
menu.
3. Press the “Type” option button to select “Pictures”.
