179
*The number of data points depends on the timebase setting and whether or
not the oscilloscope is in single or dual channel mode. More details on
how many datapoints can be saved to a CSV file can be found in the
storage chapter of this manual. The number of datapoints that can be
captured via USB device interface using the EasyScope software is
specified in the EasyScope manual.
Trigger System
Trigger Types
Edge, Pulse Width, Video, Slope,
Alternative
Trigger Source CH1,CH2, ,EXT,EXT/5, AC Line
Trigger Modes Auto, Normal, Single
Trigger Coupling AC, DC, LF reject, HF reject
Trigger Level Range CH1,CH2: ± 6 divisions from center of
screen
EXT: ±1.2 V
EXT/5: ±6 V
Trigger Level Accuracy
(typical) applicable for the
signal of rising and falling
time
≥20ns
Internal: ±(0.2 div×V/div) ( within ± 4
divisions from center of screen)
EXT: ±(6% of setting + 40 mV)
EXT/5: ±(6% of setting + 200 mV)
Horizontal System
Real Time Sampling Rate
Single Channel: 500 MSa/s
Dual Channel: 250 MSa/s (when
timebase is faster than 250
nS/div)
Highest Equivalent Sampling Rate 10 GSa/s. 25 GSa/s
Measure Display Modes MAIN, WINDOW, WINDOW
ZOOM, ROLL, X-Y
Timebase Accuracy ±100ppm measured over 1ms
interval
Horizontal Scan Range 25 nS/DIV –
50 S/DIV 10 nS/DIV –
50 S/DIV
Scan Mode: 100 mS/DIV – 50
S/DIV (1-2.5-5 sequence)
Maximum Memory Length
(interleaved) 32,000 points*
(16000 points for dual channel
operation)
