136
Table 51 - IO Setting Function Menu
Option Setting Introduction
Baud 300
2400
4800
9600
19200
38400 Set up band rate.
Note: When interfacing with the EasyScope software, it is recommended
that users use the rear panel USB interface for communication instead of
RS232 because transmission speed is noticeably slower when waveforms
are being transferred from scope to PC via RS232 interface port.
Table 52 - Utility System Function Menu 4
Option Setting Introduction
Screen-saver 1min 2min
5min 10min
15min 30min
1hour 2hour
5hour Off Set the time of Screen-saver
Recorder Record Goes into record menu to start
waveform record.
Replay Playback recordings
Option Record setups
Return Returns to previous menu
System Status
Press the “System Status” option button of the Utility Menu to view the
oscilloscope’s hardware and software configuration.
