29
Table 2 - Autoset Function Menu Items
Note: The AUTO button can be disabled. Please see “Appendix C
Disabling Auto Function” for details.
Function Setting
Acquire Mode Adjusted to Sampling
Display Format Y-T
Display Type Set to Dots for a video signal, set to Vectors
for an FFT spectrum; otherwise, unchanged
Vertical Coupling Adjusted to DC or AC according to the
input signal
V/div Adjusted
VOLTS/DIV
adjustability Coarse
Signal inverted Off
Horizontal position Center
TIME/DIV Adjusted
Trigger type Edge
Trigger source Auto detect the channel which has the input
signal
Trigger slope Rising
Trigger mode Auto
Trigger coupling DC
Trigger holdoff Minimum
Trigger level Set to 50%
