180
Trigger Sensitivity
For fixed gain ranges
1 Divisions: DC-10 MHz
1.5 Divisions: 10 MHz – max. bandwidth
EXT: 200 mVpp DC-10 MHz,
300 mVpp 10 MHz – max.
bandwidth
EXT/5: 1 Vpp DC-10 MHz,
1.5 Vpp 10 MHz - max. bandwidth
Pulse Width Trigger Trigger Modes: (>, <, =) positive Pulse
Width, (>, <, =) Negative Pulse Width
Pulse width range: 20 ns – 10 s
Video Trigger Support signal formats: PAL/SECAM,
NTSC
Trigger condition : odd field, even field,
all lines, line Num
Slope Trigger (>, <, =) Positive slope, (>, <, =)
Negative slope
Time: 20 ns-10 s
Alternative Trigger CH1 trigger type: Edge, Pulse, Video,
Slope
CH2 trigger type: Edge, Pulse, Video,
Slope
Display System
Display Mode
Color TFT 5.7 in(145 mm)
diagonal Liquid
Crystal Display
Resolution 320 horizontal by 240 vertical
pixels
Display Color 64K color
Display Contrast (Typical state) 150:1
Backlight Intensity (Typical state) 300 cd/m
2
Wave display range 8 x 12 div
Wave Display Mode Dots, Vector
Persist Off, 1 sec, 2 sec, 5 sec, Infinite
Menu Display 2 sec, 5 sec, 10 sec, 20 sec,
Infinite
Screen-Saver Off, 1 min, 2 min, 5 min, 10 min,
