76
Table 21 - Set Trigger Mode to Edge Trigger Function Menu 1
Option Setting Instruction
Type Alternative The trigger signal comes from two vertical
channels when you use alternative trigger. In
this mode, you can observe two irrelative
signals at the same time.
Source
CH1
CH2 Set trigger type information for CH1 signal.
Set trigger type information for CH2 signal.
Mode Edge
Set trigger type of the vertical channel signal
to Edge.
Slope
Triggering on rising edge.
Triggering on falling edge.
Triggering on rising edge and falling edge.
Set Up
Enter the “Trigger setup menu” (See table 2-
14).
Table 22 - Set Trigger Mode to Pulse Trigger Function Menu 1
Option Setting Instruction
Type
Alternative
The trigger signal comes from two
vertical channels when you use
alternative trigger. In this mode, you
can observe two irrelative signals at
the same time.
Source
CH1
CH2
Set trigger type information for CH1
signal.
Set trigger type information for CH2
signal.
Mode Pulse
Set trigger type of the vertical
channel signal to Pulse trigger.
