152
Table 61 - Waveform Playback Function Menu 2
Option Setting Instruction
Start Frame Set start frame.
Curr_Frame Select current frame to be
played.
End Frame Set End frame.
Return Press to return the waveform
recorder main menu.
Next Page Page 2/2 Return to the first page of
Play Back function menu.
Figure 82 - Record Menu Screen 3
To play back current record waveforms, follow these steps:
1. Press UTILITY button to enter “Utility menu”.
2. Press the “Mode” option button to select “Play Back”.
3. Press the “Play Mode” option button to select “ ” or “
”.
4. Press the “Interval” option button to select time interval between
play back frames.
