4.7 Status info of sensors and outputs
The display of the instrument status provides a simple overview of the
current modes of sensors (sensor info) and outputs in the
IQ S
ENSOR N ET .
The status display can be reached in the Settings/Service/List of all
components menu (see section 4.7).
Fig. 4-16 List of all components with sensor info
1 Call up the List of all components (see section 4.7).
2 Select the required component with <
> and confirm
with .
 Output module: The Status of output channels window
opens up (for details, refer to the operating manual of the
output module).
 Sensor: The sensor info opens up (for details, refer to the
operating manual of the selected sensor).
3 Use or to quit the window, Status of output
channels.
