System 2020 XT USB Installation
3 - 5 ba76019e01 12/2012
Determining the number
of MIQ power supply
modules
From the value determined for the power requirement, determine the
number of the MIQ power supply modules as follows:
Note
The determined number of power supply modules required in the
IQ S
ENSOR N ET can increase if the cables are very long (see section
3.4.3).
Power supply with the
aid of the MIQ/Blue PS
radio module
The MIQ/Blue PS radio module can provide power for components with
a total of up to 7 W power consumption on an IQ S
ENSOR N ET island.
The relevant details are given in the operating manual of the MIQ/
Blue PS.
Total power requirement P Number of MIQ power supply
modules
P
≤
18 W 1
18 W
<
P
≤
36 W 2
36 W
<
P
≤
54 W 3
54 W
<
P
≤
72 W 4
72 W
<
P
≤
90 W 5
90 W
<
P
≤
108 W 6
Sample configuration Power
requirement [W]
(component)
Total power
requirement P [W] (sum
of the components)
Number of
power supply
modules
required
1 MIQ/TC 2020 XT
(terminal/controller)
3.0 3.0 1
+ 1 MIQ/TC 2020 XT
(terminal)
+ 3.0 6.0 1
+ 1 NiCaVis
®
705 IQ + 8.0 14,0 1
+ 1 VisoTurb
®
700 IQ + 1.5 15,5 1
+ 1 SensoLyt
®
700 IQ + 0.2 15,7 1
+ 1 MIQ/CR3 + 3.0 18.7 2
+ 1 MIQ/CR3 + 3.0 21.7 2
+ 1 MIQ/TC 2020 XT
(terminal)
+ 3.0 24,7 2
