Overview
System 2020 XT USB
1 - 6
ba76019e01
12/2012
Direct
actions
via the
terminal
user
interface
Viewing/trans-
mitting
current data:
– Measured
values
– Status info
– Alarm
messages
Viewing/trans-
mitting
logged data:
– Measured
values
– Measured
value
status
System con-
figuration,
– save
/
load
– view
Calibra-
tion data,
view
/
transmit
Human
Terminal/controller
MIQ/TC 2020 XT
+ USB memory device
X
X
X
X
X
Human + PC
MIQ/IF232
+ IQ software pack
X
X
X
X
X
MIQ/TC 2020 XT
+ USB RS232 adapter
+ null modem cable
+ IQ software pack
X
X
X
X
X
Human + PC + modem
MIQ/TC 2020 XT
+ USB RS232 adapter
+ modem (analog, GSM, or
radio)
+ IQ software pack
X
X
X
X
X
Human + PC/mobile phone
+ modem
MIQ/TC 2020 XT
+ USB RS232 adapter
+ GSM modem
communication via SMS
X
PROFIBUS DP-V1
MIQ/(A-)PR
X
Modbus
MIQ/(A-)MOD;
Modbus RTU operation
X
MIQ/(A-)MOD;
Point-to-point communication
via RS485
X
Network (TCP/IP)
MIQ/TC 2020 XT
+ USB Ethernet adapter
X
X
X
X
X
Client + Server + PC
("data logger")
MIQ/IF232
+ IQ software pack
(+ network)
X
X
Available
functions
Who communicates
with the IQ Sensor Net
via which interface/
component
