System 2020 XT USB Technical data
8 - 5 ba76019e01 12/2012
Mechanical
construction
Electrical data
Terminal connections
Cable glands
Maximum number of
MIQ modules in a
module stack 3 plus terminal component
Enclosure material Polycarbonate with 20 % glass fiber
Weight Approx. 0.5 kg
Type of protection – IP 66
– In accordance with NEMA 4X
MIQ modules are not suitable for conduit
connection
– NEMA 3S
Nominal voltage Max. 24 VDC
via the IQ S
ENSOR N ET (for details, see
section 8.1 G ENERAL SYSTEM DATA )
Power consumption Module-dependent
(see section 3.4.2 D
RAWING UP THE POWER
RATING )
IQ S ENSOR N ET
connections
At least two in each MIQ module.
Additional connectable SENSORNET
terminator (terminating resistor)
Further connections Module-dependent
Terminal type Screw-type terminal strip, accessible by
opening the lid
Terminal ranges Solid wires:
Flexible wires:
0.2 ... 4.0 mm
2
AWG 24 ... 12
0.2 ... 2.5 mm
2
Suitable for cable
sheath diameter 4.5 - 10 mm or
9.0 - 13 mm
