Peripheral Devices Configuration
Serial port A [Enabled]
Base I/O address [3F8]
Interrupt [IRQ 4]
Serial port B [Enabled]
Mode [Normal]
Base I/O address [2F8]
Interrupt [IRQ 3]
Item Specific Help
Configure Serial port
A using options:
[Disabled]
No Configuration
[Enabled]
User Configuration
[Auto]
BIOS or OS chooses
Configuration
(OS Controlled)
D i s p l a y e d w h e n
controlled by OS
F1 ：Help ↑↓ Select Item -/+ Change Values F9：Setup Defaults
ESC ：Exit →← Select Menu Enter Select Sub-menu F10：Save and Exit
PhoenixBIOS SETUP UTILITY
Advanced
The following items appears only when you set serial Port A as Enabled.
The following items appears only when you set Serial Port B as Enabled.
5.4.5 Peripheral Devices Configuration
This menu shows the peripheral devices configuration settings. Select an
item then press to display the configuration options.
Serial port A [Enabled]
Allows you to configure serial port A. Configuration options: [Disabled]
[Enabled]
Base I/O address [378]
Allows you to select the base I/O address for serial port A.
Configuration options: [3F8] [2F8] [3E8] [2E8]
Interrupt [IRQ 4]
Allows you to set the interrupt for serial port A. Configuration options:
[IRQ 3] [IRQ 4]
Serial port B [Enabled]
Allows you to configure serial port B. Configuration options: [Disabled]
[Enabled]
