ASUS RS162-E4/RX4

The CPU fits in only one correct orientation. DO NOT force the CPU

into the socket to prevent bending the connectors on the socket and

damaging the CPU!

6. Close the load plate (A), then

push the load lever (B) until it

snaps into the retention tab.

If you want to install a

second CPU, follow the steps

above.

2.2.2 Install the CPU heatsink

To install the CPU heatsink:
1. Put the heatsink on the installed

CPU, match the screws with the

screw holes on the board.

2. Fasten two screws at a time in a

diagonal sequence, and then the

other two.

3. Repeat step 1-2 to install the

second CPU heatsink.
