ASUS RS162-E4/RX4 -1
Chipset Configuration
Cystal Beach Configuration Enable [Enabled]
SERR Signal Condition [Single Bit]
Demand Scrub Enable [Enabled]
Patrol Scrub Enable [Enabled]
4GB PCI Hole Granularity [256 MB]
Memory Branch Mode [Interleave]
Branch 0 Rank Interleave [4:1]
Branch 0 Rank Sparing [Disabled]
Branch 1 Rank Interleave [4:1]
Branch 1 Rank Sparing [Disabled]
Enhanced x8 Detection [Enabled]
Force ITK Config Clocking [Disabled]
FBDIMM(s) Temal Throttling [ASUS MemCool F]
Item Specific Help
Enable Configuration/
Memory mapped accesses
to the Crystal Beach
Configuration space
located in Device 8,
Fn 0, and Fn 1.
F1 ：Help ↑↓ Select Item -/+ Change Values F9：Setup Defaults
ESC ：Exit →← Select Menu Enter Select Sub-menu F10：Save and Exit
PhoenixBIOS SETUP UTILITY
Advanced
Echo TPR [Disabled]
Configuration options: [Disabled] [Enabled]
Discrete MTRR Allocation [Disabled]
Configuration options: [Disabled] [Enabled]
Intel EIST support [Enabled]
Enable or disable the Intel EIST function. Configuration options: [Disabled]
[Enabled].
5.4.2 Chipset Configuration
This menu shows the chipset configuration settings. Select an item then
press to display a pop-up menu with the configuration options.
Crystal Beach Configure Enable [Enabled]
Allows you to enable or disable the Configuration/Memory mapped accesses
to the Crystal Beach Configuration space located in Device 8, Fn 0, and Fn 1.
Configuration options: [Disabled] [Enabled]
SERR Signal Condition [Single Bit]
Allows you to select the ECC error that the SERR# asserts. Configuration
options: [None] [Single Bit] [Multiple Bit] [Both]
Demand Scrub Enable [Enabled]
Allows you to enable or disable the Demand Scrub function. Configuration
options: [Disabled] [Enabled]
