ASUS RS162-E4/RX4 1-
1.2 System specifications
The ASUS RS162-E4/RX4 is a 1U barebone server system featuring the
ASUS DSBF-DR12 motherboard. The server supports dual Intel LGA771
Xeon processors with EM64T technology, plus other latest technologies
through the chipsets onboard.
Chassis Rackmount 1U (R12)
Motherboard ASUS DSBF-DR12
Chipset North Bridge: Intel® 5000P MCH
South Bridge: Intel® ESB2E
I/O Bridge: Intel® PXH-V
CPU Supports Dual LGA771 sockets Intel® Xeon processors
Supports Dual-Core Xeon Dempsey1066/Woodcrest1333 processor
Supports Intel® Extended Memory 64-bit Technology (EM64T)
Supports Enhanced Intel® SpeedStep Technology (EIST)
Memory 12 x 240-pin Fully Buffer DIMM (FBD) sockets support registered
ECC DDRII-667/533 MHz memory modules
Supports 256MB up to 48GB system memory
LAN 2 x Gigabit LAN (Intel® ESB2E supports)
VGA ATI ES1000(RN50) VGA controller
Supports 32MB display memory
Storage LSI SAS1068 controller supports:
- 8 x SAS drives, supports RAID 0, RAID 1, RAID 0+1 and RAID 1E
configuration
- Zero-Channel RAID card (optional)
Expansion slots 1 x full-length 64-bit/133MHz 3V PCI-X slot (on a riser card)
1 x full-length PCI-Express x8 slot (on a riser card)
1 x half-length PCI-Express x8 slot (on a riser card)
1 x PCI-X slot for LSI 8300XLP ZCR Management Board
Front panel 4 x 3.5-inch hot-swappable SAS/SATA-II HDD bays
1 x Slim optical drive
2 x USB 2.0 ports
Power switch
Reset switch
Location switch
LEDs: Power, HDD access, location, message, LAN 1, LAN 2
HDD LEDs: Status, activity
(continued on the next page)
