Chapter 2: Hardware setup

2.8.6 Optical drive

The system come with a DVD drive (CD-ROM/DVD-ROM), follow the steps

below if you want to change it:

2. Remove the six screws (refer to

the figure for the locations) on

the left and right sides of the

front side of the top cover panel.

3. Loosen the two screws that

scure the top cover panel to the

rear panel (refer to the figure for

the locations). Please note that

do not remove the screws when

loosenning them.

4. Push the back cover panel

backward until it is half inch

away from the front side of the

top cover panel.

1. Push the blue button to the right

side and pull the lever outward

(see the figure) to remove the

hard disk tray.
