Asus RS162-E4/RX4 - Manual (Page 122)

Chapter 6: RAID configuration -10
6.2.3 Integrated Striping (IS) volume
Overview
The Integrated Striping (IS) feature provides RAID 0 functionality,
supporting volumes with two to eight disks. You may combine an IS volume
with an IM or IME volume.
Creating Integrated Striping volumes
Do not combine Serial ATA and SAS disks in one volume.
To create an IS volume:
1. Turn on the system after installing all SAS hard disk drives.
2. During POST, press to enter the SAS configuration utility.
LSI Logic Corp. MPT SAS BIOS
MPTBIOS-6.05.06.00 (2005.01.16)
Copyright 2000-2005 LSI Logic Corp.
*** RELEASE VERSION ***
Press Ctrl-C to start LSI Logic Configuration Utility...
3. The Adapter Properties screen appears. Use the arrow keys to select
RAID Properties, then press .
