Page 34

Chapter 2: Hardware setup

-1

2. Prepare the SAS expansion

module. connect it to the riser

card and secure it.

3. Put back the riser card to its slot

on the board.

4. Connect the cable.

2.5.5 Install ZCR card (Optional)

The system package provide an optional ZCR card. If you want to install it,

follow the steps below:

1. The ZCR card comes with a

battery module card(optional),

before you install the ZCR card,

remove the battery module card

and install a battery first.
