ProBee-ZE20S-SExx User Guide Rev 1.8 93
AT+TSYNC
Response
+
+
7.12.15 AT+CBKESTART or AT+CS
Description
Start ‘Initiate Key Establishment Request’ command(Key Establishment cluster) to
destination node and exchange static and ephemeral data. This command should
be performed at Trust Center(coordinator) node or destination node should be
Trust Center(coordinator) node.
Execute
AT+DEST=
CR>
AT+CBKESTART
AT+CBKESTART=
CR>
Response
CBKE DEST:
OK or ERROR
7.12.16 AT+CBKEPARTNER or AT+CP
Description
Set destination node as CBKE partner node for exchanging partner link key. This
command should not be performed at Trust Center(coordinator) node nor
destination node should not be Trust Center(coordinator) node.
Execute
AT+DEST=
CR>
AT+CBKEPARTNER
AT+CBKEPARTNER=
t>
Response
CBKE DEST:
OK or ERROR
7.12.17 AT+IMPLICIT or AT+IM
Description Get/Set CBKE Data Token - Device Implicit Cert.
Execute AT+IMPLICIT? AT+IMPLICIT=
Response
CBKE DATA TOKEN IS EMPTY or CBKE DATA TOKEN IS LOCKED
DEVICE IMPLICIT CERT:
CA PUBLIC KEY & DEVICE PRIVATE KEY:
OK
7.12.18 AT+PUBLICKEY or AT+PK
Description Get/Set CBKE Data Token - CA Public Key & Device Private Key
Execute AT+PUBLICKEY? AT+PUBLICKEY=
Response
CBKE DATA TOKEN IS EMPTY or CBKE DATA TOKEN IS LOCKED
DEVICE IMPLICIT CERT:
