ProBee-ZE20S-SExx User Guide Rev 1.8 50
CBKE DATA TOKEN IS EMPTY # Now CBKE Data Token is unlocked and empty
DEVICE IMPLICIT CERT(BUFFER):
030505D6AED0C401C4003AE871FA2AF4697FB89B5A8D000195AABBCC0000544553545345434101
091AABBAABBCCDDEEF
CA PUBLIC KEY & DEVICE PRIVATE KEY(BUFFER):
0200FDE8A7F3D1084224962A4E7C54E69AC3F04DA6B800F156135BECA22BC66388B26730E03852
5144BE6C
OK
AT+SETCBKEKEY # Lock CBKE Data Token
CBKE DATA TOKEN IS LOCKED # Now CBKE Data Token is locked
DEVICE IMPLICIT CERT:
030505D6AED0C401C4003AE871FA2AF4697FB89B5A8D000195AABBCC0000544553545345434101
091AABBAABBCCDDEEF
CA PUBLIC KEY & DEVICE PRIVATE KEY:
0200FDE8A7F3D1084224962A4E7C54E69AC3F04DA6B800F156135BECA22BC66388B26730E03852
5144BE6C
OK
If CBKE Data Token is vaild and it is locked successfully, you can see ‘GoodCert’ message in AT+INFO.
AT+INFO
Security Level: 05, Security Profile: SE Full
SE Security Info: RealEcc, RealCbke, GoodCert # GoodCert when
# CBKE Data Token is
End-point count: 1 # valid and locked
End-point No.1: ProfileID-0x0109, DeviceID-0x0500
Server-side cluster: 0x0000 (Basic)
Server-side cluster: 0x0003 (Identify)
Server-side cluster: 0x000A (Time)
Server-side cluster: 0x0701 (Demand Response and Load Control)
Server-side cluster: 0x0700 (Price)
Server-side cluster: 0x0703 (Messaging)
Client-side cluster: 0x0800 (Key establishment)
Server-side cluster: 0x0800 (Key establishment)
OK
Example) Set test certificate to ProBeeSEID(end-device)
#Screen of ProBeeSEID(end-device)
AT+LONGADDR # Get long address
