ProBee-ZE20S-SExx User Guide Rev 1.8 34
Example) Use AT+KEYTABLE in router or end-device to get Pre-configured Link Key
AT+KEYTABLE # Input AT+KEYTABLE for getting Link Key
NETWORK KEY: FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF
LINK KEY TABLE
#|IEEE_ADDRESS |TYPE|AUTH|KEY
*|0000000000000000|LINK|NO |1A51778BAF98BEFAD6B41215F402C979
# KEY(1A51778BAF98BEFAD6B41215F402C979) value is
# Pre-configured Link Key of current node
1/6 ENTRIES USED
OK # Response
AT+LONGADDR # Get long address of joining node
0001951122334455
OK # Response
Example) Use AT+KEYTABLE in Coordinator to add Pre-configured Link Key
AT+KEYTABLE=0,0001951122334455,1A51778BAF98BEFAD6B41215F402C979
# Add Pre-configured Link Key to Key Table
OK # Response
Then the joining node can allow to join to network.
3.5 Setting up ZE20S as a Router
A router is a full-function routing device that relays messages and can act as a parent to other nodes.
These devices must be always powered on.
To configure the ZE20S as a ZigBee router, please follow the steps below.
 Configure the CBKE Data Token
 Optionally, configure the Install Code
 Configure the ZE20S node type as a router.
 Optionally, select the channel mask. Otherwise, the ZE20S will use the default channel mask.
 Optionally, set up the PAN ID and/or the extended PAN ID. Otherwise, the ZE20S will scan and
join the ZigBee network found automatically.
 Permit joining when other router or end-device tries to join the ZigBee network.
3.5.1 CBKE Data Token Configuration
Before operating ZE20S module as Smart Energy node, user should set CBKE certificate to CBKE Data
