DS1862
XFP Laser Control and Digital Diagnostic IC
34
____________________________________________________________________
92h
V
CC2/3
SCALE ........................... < R-Module / W-Module >
register controls the scale value for the V
CC2/3
monitor channel.
94h
• BIAS SCALE.....................< R-Module / W-Module >
register controls the scale value for the BIAS monitor channel.
96h
• TX-P SCALE .....................< R-Module / W-Module >
register controls the scale value for the TX-P (BMD) monitor channel.
98h
• RX-P SCALE.....................< R-Module / W-Module >
register controls the scale value for the RX-P (RSSI) monitor channel.
9Ah
• AUX1 SCALE ...................< R-Module / W-Module >
register controls the scale value for the AUX1MON monitor channel.
9Ch
• AUX2 SCALE ...................< R-Module / W-Module >
register controls the scale value for the AUX2MON monitor channel.
A0h
• TEMP OFFSET .................< R-Module / W-Module >
register controls the offset value for the internal temperature monitor channel.
A2h
• V
CC2/3
OFFSET................ < R-Module / W-Module >
trols the offset value for the V
CC2/3
monitor channel.
A4h
• BIAS OFFSET...................< R-Module / W-Module >
trols the offset value for the BIAS monitor channel.
A6h
• TX-P OFFSET ...................< R-Module / W-Module >
trols the offset value for the TX-P (BMD) monitor channel.
A8h
• RX-P OFFSET...................< R-Module / W-Module >
trols the offset value for the RX_P (RSSI) monitor channel.
AAh
• AUX1 OFFSET..................< R-Module / W-Module >
trols the offset value for the AUX1MON monitor channel.
ACh
• AUX2 OFFSET..................< R-Module / W-Module >
trols the offset value for the AUX2MON monitor channel.
B0h
• LUT INDEX PNTR.............< R-Module / W-Module >
vaue for the LUT. It is automatically updaded (in normal operating mode) and can
be read or overwriten using the TEN and AEN bits.
