DS1862
XFP Laser Control and Digital Diagnostic IC
28 ____________________________________________________________________
TABLE 01H (SERIAL ID MEMORY)
WORD 0 WORD 1 WORD 2 WORD 3 ADDRESS
(hex) Byte 0/8 Byte 1/9 Byte 2/A Byte 3/B Byte 4/C Byte 5/D Byte 6/E Byte 7/F
80 <2> EE EE EE EE EE EE EE EE
88 <2> EE EE EE EE EE EE EE EE
90 <2> EE EE EE EE EE EE EE EE
98 <2> EE EE EE EE EE EE EE EE
A0 <2> EE EE EE EE EE EE EE EE
A8 <2> EE EE EE EE EE EE EE EE
B0 <2> EE EE EE EE EE EE EE EE
B8 <2> EE EE EE EE EE EE EE EE
C0 <2> EE EE EE EE EE EE EE EE
C8 <2> EE EE EE EE EE EE EE EE
D0 <2> EE EE EE EE EE EE EE EE
D8 <2> EE EE EE EE V CC2/3 _Sel
LO Mem 6Eh
enable
AUX1/2 Unit
Select
EE
E0 <2> EE EE EE EE EE EE EE EE
E8 <2> EE EE EE EE EE EE EE EE
F0 <2> EE EE EE EE EE EE EE EE
F8 <2> EE EE EE EE EE EE EE EE
EXPANDED BYTES
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 BYTE
(hex)
BYTE/WORD
NAME bit 15 bit 14 bit 13 bit 12 bit 11 bit 10 bit 9 bit 8 bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
EE EE EE EE EE EE EE EE EE
DC <2> Reserved Reserved Reserved Reserved Reserved Reserved Reserved V CC2/3 _Sel
DD <2> LO Mem EN Reserved
Enable 6Eh,
bit 6
Enable 6Eh,
bit 3
Reserved Reserved Reserved Reserved LOCK-bit
DE <2> AUX1/2 UNIT SEL AUX1-SEL 2 3 AUX1-SEL 2 2 AUX1-SEL 2 1 AUX1-SEL 2 0 AUX2-SEL 2 3 AUX2-SEL 2 2 AUX2-SEL 2 1 AUX2-SEL 2 0
Note: Byte DDh <6:5> of Table 01h enables bit 6 and bit 3 of Byte 6Eh in the lower memory.
TABLE 02H (HOST USER MEMORY)
WORD 0 WORD 1 WORD 2 WORD 3 ADDRESS
(hex) Byte 0/8 Byte 1/9 Byte 2/A Byte 3/B Byte 4/C Byte 5/D Byte 6/E Byte 7/F
80–FF <3> EE EE EE EE EE EE EE EE
TABLE 03H (MODSET LOOK-UP TABLE)
WORD 0 WORD 1 WORD 2 WORD 3 ADDRESS
(hex) Byte 0/8 Byte 1/9 Byte 2/A Byte 3/B Byte 4/C Byte 5/D Byte 6/E Byte 7/F
80–87 <4>
EE,
< -40 °C
EE,
-40 °C
EE,
-38 °C
EE,
-36 °C
EE,
-34 °C
EE,
-32 °C
EE,
-30 °C
EE,
-28 °C
88–BF <4> — — — — — — — —
C0–C7 <4>
EE,
+88 °C
EE,
+90 °C
EE,
+92 °C
EE,
+94 °C
EE,
+96 °C
EE,
+98 °C
EE,
+100 °C
EE, > +102 °C
