RF22
Version: 0.1 Date: 12/23/2008
Tel: +86-755-82973805 Fax: +86-755-82973550 E-mail: [email protected] http://www.hoperf.com 74
Bit Name Function
7:0 hden[23:16]
Header Enable 2.
3rd byte of the check header.
Register 45h. Header Enable 1
Bit D7 D6 D5 D4 D3 D2 D1 D0
Name hden[15:8]
Type R/W
Reset value = 00000000
Bit
Name Function
7:0 hden[15:8]
Header Enable 1.
2nd byte of the check header.
Register 46h. Header Enable 0
Bit D7 D6 D5 D4 D3 D2 D1 D0
Name hden[7:0]
Type R/W
Reset value = 00000000
Bit Name Function
7:0 hden[7:0] Header Enable 0.
1st byte of the check header.
Register 47h. Received Header 3
Bit D7 D6 D5 D4 D3 D2 D1 D0
Name rxhd[31:24]
Type R
Reset value = 00000000
Bit Name Function
7:0 rxhd[31:24] Received Header 3.
4th byte of the received header.
Register 48h. Received Header 2
Bit D7 D6 D5 D4 D3 D2 D1 D0
Name rxhd[23:16]
Type R
Reset value = 00000000
Bit
Name Function
7:0 rxhd[23:16]
Received Header 2.
3rd byte of the received header.
Register 49h. Received Header 1
Bit D7 D6 D5 D4 D3 D2 D1 D0
Name rxhd[15:8]
Type R
Reset value = 00000000
Bit
Name Function
7:0 rxhd[15:8]
Received Header 1.
2nd byte of the received header.
