Table14. Packet Handler Registers
Addr R/W Function/Description D7 D6 D5 D4 D3 D2 D1 D0 POR Def.
30 R/W Data Access Control enpacrx lsbfrst crcdonly * enpactx encrc crc[1] crc[0] 1Dh
31 R EzMAC status 0 rxcrc1 pksrch pkrx pkvalid crcerror pktx pksent -
32 R/W Header Control 1 enbcast[3] enbcast[2] enbcast[1] enbcast[0] hdch[3] hdch[2] hdch[1] hdch[0] 0Ch
33 R/W Header Control 2 hdlen[2] hdlen[1] hdlen[0] fixpklen synclen[1] synclen[0] prealen[8] 22h
34 R/W Preamble Length prealen[7] prealen[6] prealen[5] prealen[4] prealen[3] prealen[2] prealen[1] prealen[0] 07h
35 R/W Preamble Detection Control preath[4] preath[3] preath[2] preath[1] preath[0] spare spare spare 20h
36 R/W Sync Word 3 sync[31] sync[30] sync[29] sync[28] sync[27] sync[26] sync[25] sync[24] 2Dh
37 R/W Sync Word 2 sync[23] sync[22] sync[21] sync[20] sync[19] sync[18] sync[17] sync[16] D4h
38 R/W Sync Word 1 sync[15] sync[14] sync[13] sync[12] sync[11] sync[10] sync[9] sync[8] 00h
39 R/W Sync Word 0 sync[7] sync[6] sync[5] sync[4] sync[3] sync[2] sync[1] sync[0] 00h
3A R/W Transmit Header 3 txhd[31] txhd[30] txhd[29] txhd[28] txhd[27] txhd[26] txhd[25] txhd[24] 00h
3B R/W Transmit Header 2 txhd[23] txhd[22] txhd[21] txhd[20] txhd[19] txhd[18] txhd[17] txhd[16] 00h
3C R/W Transmit Header 1 txhd[15] txhd[14] txhd[13] txhd[12] txhd[11] txhd[10] txhd[9] txhd[8] 00h
3D R/W Transmit Header 0 txhd[7] txhd[6] txhd[5] txhd[4] txhd[3] txhd[2] txhd[1] txhd[0] 00h
3E R/W Transmit Packet Length pklen[7] pklen[6] pklen[5] pklen[4] pklen[3] pklen[2] pklen[1] pklen[0] 00h
3F R/W Check Header 3 chhd[31] chhd[30] chhd[29] chhd[28] chhd[27] chhd[26] chhd[25] chhd[24] 00h
40 R/W Check Header 2 chhd[23] chhd[22] chhd[21] chhd[20] chhd[19] chhd[18] chhd[17] chhd[16] 00h
41 R/W Check Header 1 chhd[15] chhd[14] chhd[13] chhd[12] chhd[11] chhd[10] chhd[9] chhd[8] 00h
42 R/W Check Header 0 chhd[7] chhd[6] chhd[5] chhd[4] chhd[3] chhd[2] chhd[1] chhd[0] 00h
43 R/W Header Enable 3 hden[31] hden[30] hden[29] hden[28] hden[27] hden[26] hden[25] hden[24] FFh
44 R/W Header Enable 2 hden[23] hden[22] hden[21] hden[20] hden[19] hden[18] hden[17] hden[16] FFh
45 R/W Header Enable 1 hden[15] hden[14] hden[13] hden[12] hden[11] hden[10] hden[9] hden[8] FFh
46 R/W Header Enable 0 hden[7] hden[6] hden[5] hden[4] hden[3] hden[2] hden[1] hden[0] FFh
47 R Received Header 3 rxhd[31] rxhd[30] rxhd[29] rxhd[28] rxhd[27] rxhd[26] rxhd[25] rxhd[24] —
48 R Received Header 2 rxhd[23] rxhd[22] rxhd[21] rxhd[20] rxhd[19] rxhd[18] rxhd[17] rxhd[16] —
49 R Received Header 1 rxhd[15] rxhd[14] rxhd[13] rxhd[12] rxhd[11] rxhd[10] rxhd[9] rxhd[8] —
4A R Received Header 0 rxhd[7] rxhd[6] rxhd[5] rxhd[4] rxhd[3] rxhd[2] rxhd[1] rxhd[0] —
4B R Received Packet Length rxplen[7] rxplen[6] rxplen[5] rxplen[4] rxplen[3] rxplen[2] rxplen[1] rxplen[0] —
6.5. Data Whitening, Manchester Encoding, and CRC
Data whitening can be used to avoid extended sequences of 0s or 1s in the transmitted data stream to achieve a more
uniform spectrum. When enabled, the payload data bits are XORed with a pseudorandom sequence output from the
built-in PN9 generator. The generator is initialized at the beginning of the payload. The receiver recovers the original
data by repeating this operation. Manchester encoding can be used to ensure a dc-free transmission and good
synchronization properties. When Manchester encoding is used, the effective datarate is unchanged but the actual
datarate (preamble length, etc.) is doubled due to the nature of the encoding. The effective datarate when using
Manchester encoding is limited to 64 kbps. Data Whitening and Manchester encoding can be selected with "Register
70h. Modulation Mode Control 1". The CRC is configured via "Register 30h. Data Access Control".
