5. Parts List
PNEG-1813 Electronic Distributor Control 47
12" 6 Hole 45° Distributor Assembly Electronic Control (DFB12645G-EC) Parts List
Ref # Part # Description Qty
1 DFB12645G 12" 6 Hole 45° Distributor Assembly 1
2 DEC0009 Weldment, Shaft and Flag, 1/2 HP Distributor Control 1
3 DEC0005 Weldment, Enclosure, 1/2 HP Distributor Control 1
4 DEC0014 Angle, Sensor Plate Mounting, 1/2 HP Distributor Control 1
5 DEC0006 Bracket, Proximity Sensor, 1/2 HP Distributor Control 1
6 DEC0015 Gear Motor, DBL WRM, 1/2 HP, 400:1, Distributor Control 1
7 DEC0003 Bracket, Motor Mount, 1/2 HP Distributor Control 1
8 DEC0016 Bracket, Encoder Mount, Distributor Control 1
9 DEC0017 Encoder, INCR, 2048 PPR, 30 mm, Distributor Control 1
10 DEC0018 Sensor, Proximity, Inductive, 12 mm, S=4 2
11 DEC0019 Box, Junction, 1/2 HP Distributor Control 1
12 DEC0013 Cover, Side Access, 1/2 HP Distributor Control 2
13 DEC0012 Cover, Enclosure Bottom, 1/2 HP Distributor Control 1
14 S-2041 Split Lock Washer 1/4" ZN 18
15 S-1429 Bolt, HHCS 1/4"-20 x 3/4" ZN Grade 2 29
16 S-2126 Flat Washer 1/4" x 2-5/8" SAE ZN Grade 2 11
17 S-6998 Bolt, HHCS 1/4"-20 x 1" ZN Grade 5 4
18 S-7025 Nylock Nut 1/4"-20 ZN Grade 5 15
19 S-9288 Spring Pin 1/4" x 2-1/2" Plain Steel Slotted Rolled 2
20 S-7469 Bolt, HHCS 3/8"-16 x 1" ZN Grade 5 5
21 S-7383 Nylock Nut 3/8"-16 ZN Grade 5 4
22 S-10200 Fender Washer 3/8" x 1-1/2" O.D. ZN 1
23 S-280 Screw, SDS #10-16 x 5/8" HWH ZN 4
24 S-7223 Split Lock Washer #10 ZN 3
25 S-10167 Bolt, SHCS #10-32 x 1/4" ZN 3
26 DEC0021 Bracket, Motor Mount Short, 1/2 HP Distributor Control 1
27 DC-2160 Decal, Caution, Do not Operate with Access Panel 1
28 DC-2159 Decal, Warning, Rotating Spout can Crush and Cut 1
