3. Installation
PNEG-1813 Electronic Distributor Control
23
Motor Cable to Motor Junction Box Fitting Connections
Remove the four (4) motor junction box cover screws and the motor junction box cover as shown
in
Connect the motor cable to the motor junction box using suitable fittings.
Figure 3O Cable fitting connection to motor junction box.
Motor junction
box cover
Motor junction
box
Motor junction
box cover
screw
Motor cable
