4. Operation Procedures
PNEG-1813 Electronic Distributor Control 41
3. Insert the desired value and press “enter”.
NOTE: Entering a value larger than the existing value will move spout position to the left, entering a
smaller value will move the position to the right.
4. Select “OK” to return to “Setup Menu”.
5. Verify spout alignment with distributor. See “Verifying Spout Alignment” on Page 36 .
Offset All
1. From the “Setup Menu”, select “Position Locations” to bring up the “Modify Spout Positioning” screen.
2. In “Modify Spout Positioning” screen select the “0” key pad next to “OFFSET ALL”. A number keypad
will display. (See Figure 4R.)
Figure 4R Help Menu Screen
3. Insert the desired value and press “enter”.
To offset the spouts to the left, use a positive value and to offset to the right, use a negative value.
NOTE: A maximum offset at any one time is ± 5.
4. Select “OK” to return to “Setup Menu”.
5. Verify each spout alignment with distributor. See “Verifying Spout Alignment” on Page 36 .
