Installation – Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1813 User Manual
Page 25
3. Installation
PNEG-1813 Electronic Distributor Control
25
Motor Wiring to Motor Junction Box Electrical Connections
Connect the motor wiring to the motor wiring terminal block as shown in
and re-install the motor
junction box cover and screws.
Figure 3Q Motor Wiring to Motor Junction Box Electrical Connections
Motor wiring
terminal block
Wire W
Wire V
Wire U
Ground wire
Motor cable
