Grain Systems Bucket Elevtors, Conveyors, Series II Sweeps PNEG-1813 User Manual
Page 29
3. Installation
PNEG-1813 Electronic Distributor Control
29
Power Supply Wiring to Control Panel Electrical Connections
NOTE: Ensure the power supply voltage source is OFF before installation.
Install power supply cable through the control panel using suitable hardware as shown in
.
Connect the power supply hot wires to the control panel circuit breakers as shown in
.
Connect the power supply ground wire as shown in
to the ground terminal block as shown
in
.
Figure 3U Control Panel Wiring from Motor Electrical Connections
Control panel
circuit breakers
Hot wires
Power cable
hardware
Power supply
ground wire
