3. Installation
28
PNEG-1813 Electronic Distributor Control
Control Panel Wiring from Motor Electrical Connections
Connect the motor wiring to the motor power terminal block in the control panel as shown in
Figure 3T Control Panel Wiring from Motor Electrical Connections
Ground terminal block
Wire U
Wire W
Wire V
Ground wire
