3. Installation
22
PNEG-1813 Electronic Distributor Control
Control Panel Cable to Distributor Fitting Connections
Connect the motor cable from the control panel to the distributor enclosure (DEC0005) and connect the
proximity sensors and encoder cable from the control panel to the junction box (DEC0019) using suitable
fittings.
Figure 3N Cable fitting connections to distributor enclosure and junction box.
Enclosure (DEC0005)
Motor cable
Proximity sensors
and encoder cable
Junction box
(DEC0019)
