14.1a ME
Gas sampling and gas conditioning technology
51
Gas conditioning unit version CSS-VC..
(C) Consumable parts,
(E) Recommended spare parts
(T) Spare parts
Recommended quantity
in operation [years]
Article No.
Description
V/I/T
1
2
3
Aerosol filter CLF5
90F2005
Filter element type CLF-5 for liquid particulate
filters CLF and CLF-5.
E
1
2
3
90F0040
O-ring (26) for the filter head. Material: Viton.
E
1
2
3
90F3530
CLF-5/W Spare parts set I, filter frit, membrane
filters, flat ring washer, O-ring.
E
1
2
3
Sample gas pump N3/5/9
90P2120
Moulded diaphragm type S3, for N3-N5 KPE,
material: Viton/PTFE.
V
1
2
3
90P2110
Valve reed type V3, for N3-N5 KPE, 1 piece,
material: Viton.
V
2
4
6
90P2115
O-ring type O3, for N3-N5 KPE, 1 pcs, Material:
Viton.
V
2
4
6
90P2220
Moulded diaphragm type S9 for N9 KPE,
material: Viton/PTFE.
V
1
2
3
90P2211
Valve plate with gasket for N9 KPE, 1 piece,
material: Viton.
V
2
4
6
Peristaltic pump SR25.2:
90P1007
SR25 pump hose with PVDF hose connector DN
4/6mm
V
1
2
4
90P1010
1 set of pressure springs for roller support of
SR25.2 (set = 4 pieces)
V
1
2
3
90P1020
Roller support complete for SR25.2
E
-
-
1
90P1045
Pressure roller (1 pc.) for SR25.2
V
-
2
4
90P1050
Belt for SR25.2
T
1
1
1
90P1025
S-lock for SR25.2
T
1
1
1
90P1031
Hose pump head complete for SR25.2 without
synchronous motor and transmission
T
1
1
1
Flow meter FM40:
90A0015
Flow meter glass for FM40
Measuring range 7-70 l/h air
T
-
1
1
94F0010
Flow meter glass for FM40
Measuring range 15-150 l/h air
T
-
1
1
94F0015
Flow meter glass for FM40
Measuring range 25-250 l/h air
T
-
1
1
90A0018
Viton O-ring 9 for FM40 glass
E
2
4
6
Miscellaneous:
90K6030
Fuse 4A T, 5x20mm for CSS...
E
5
5
5
Hose and hose fittings:
05V3215
Bulkhead union SV-PVDF DN 4/6
E
2
2
2
05V6600
Clamping ring 4/6 PVDF see above.
E
5
10
10
05V6605
Nut M10-4/6 PVDF see above.
E
5
10
10
02B1000
PTFE hose NW 4/6 (m)
T
1
2
3
10T1000
Tubing cutter
T
1
1
1
