14.1a ME Gas sampling and gas conditioning technology 11
8.1 TECHNICAL SPECIFICATIONS FOR THE EXPANSION MODULES
Module Communication module Status module Temperature control module Backflush module
Article No. 91 B 8620 91 B 8630 91 B 8640 91 B 8650
Power supply 24V DC + - 20% internal
Earthing L <3m - L <3m
Communication
M & C system (RJ-45) L
<3m
- - -
Inputs
2 x PT100 (2-wire)
L <30 m or
2 x thermocouples
L <30 m
- -
Switching input
(Pressure switch)
Connection cable
length
see above - - Max. 100 m
Outputs -
Function: Status
1 potential-free
contact
(Changeover
switch 230VAC
1A)
(Can be used up
to 24V, 500mA!)
1 solid-state
output
230VAC 3A
Function: Pump1
1 solid state
output
230VAC 3A
Function: Pump 2
1 solid-state
output
230VAC 3A
2 x small signal digital output for
solid state relay control
24V max. 20mA
Function: High temperature
alarm
2 potential-free contacts
(N/O contact 230VAC 1A)
(can be used up to 24V
500mA!)
Function: Low temperature
alarm
2 potential-free contacts
(N/O contact 230VAC 1A)
(can be used up to 24V
500mA!)
Function: Measurement
1 potential-free contact
(Changeover switch
48VAC 1A)
(can be used up to 24V
500mA!)
Function: Backflush 1
1 solid-state output
230VAC 3A
Function: Control air
1 solid-state output
230VAC 3A
Function: Backflush 2
1 solid state output
230VAC 3A
Connection cable
length
- Max. 100 m
Ambient temperature
max.
+ 60 ° C
Dimensions: 72 x 88 x 20mm 72 x 68 x 30mm 72 x 68 x 18mm 72 x 79 x 30mm
Weight 90 g 100 g 48 g 106 g
The power consumption of all modules together is max. 140mA at 24V => 3.36 W.
