IPDirector Version 5.9 – User Manual – Part 6: Playout – Playlist Panel
EVS Broadcast Equipment – January 2011
Issue 5.9.B
23
P
OST
R
OLL
A
REA
This area indicates whether a post roll is activated or not.
The post roll is the ability to play an element a few seconds after its defined OUT
point, as far as there is enough A/V material in the guardband.
If it is activated, the post roll duration is displayed and the background of the zone
is green.
If it is not activated, the area displays ‘POST ROLL is OFF’ and the background of
the zone is grey.
Refer to section 1.7.14 ‘Working with Post-Roll’ on page 122 for more details on
the Post-Roll function.
