Prestige 480 ISDN Router
Dial-In Server Configuration 6-13
LAN 2
Figure 6-11 LAN2 LAN-to-LAN Application
Testing Callback with your Connection
Go to Menu 24.4.5 of the Prestige on LAN 1 and enter the numbers that correspond to the menu in
the above LAN 1.
Figure 6-12 Testing Callback with your Connection
Menu 11.1 - Remote Node Profile
Rem Node Name= LAN_1
Active= Yes
Call Direction= Both
Incoming:
Rem Login= lan1
Rem Password= *******
Rem CLID=
Call Back= Yes
Outgoing:
My Login= lan2
My Password= ********
Authen= CHAP/PAP
Pri Phone #= 5678
Sec Phone #=
Edit PPP Options= No
Rem IP Addr= 192.168.1.1
Edit IP= No
Telco Option:
Transfer Type= 64K
Allocated Budget(min)=
Period(hr)=
Carrier Acess Code=
Nailed-Up Connection= N/A
Toll Period (Sec)= 0
Session Options:
Edit Filter Sets= No
Idle Timeout(sec)= 100
Enter here to CONFIRM or ESC to CANCEL:
Set Call Direction
and Call Back to
Both and Yes
respectively.
Start dialing for node …
### Hit any key to continue ###
$$$ DIALING dev=2 ch=0…..
$$$ OUTGOING-CALL phone (123)
$$$ CALL CONNECT speed <64000> type<2> chan<0>
$$$ LCP opened
$$$ PAP sending user/pswd
$$$ LCP closed
$$$ Recv’d TERM-REQ
$$$ Recv’d TERM-ACK state 4
$$$ LCP stopped
$$$ ANSWER CONNECTED ch=7743 bc
$$$ LCP opened
$$$ IPCP negotiation started
$$$ IPCP opened Prestige on LAN1
calls Prestige on
LAN2
PAP
authentication
Successful
