Prestige 480 ISDN Router
System Maintenance 11-3
If you enter 9 in the Press Command field you will see the following menu:
Figure 11-3 Menu 24.1 after Toggle Status
The following table describes the fields present in Menu 24.1 - System Maintenance - Status. It
should be noted that these fields are READ-ONLY and are meant to be used for diagnostic
purposes.
Table 11-1 System Maintenance - Status Menu Fields
Field Description
ISDN Shows which ISDN line(s) is in use.
Chan Shows statistics for B1 and B2 channels respectively. This is the information
displayed for each channel:
Status Shows the status of the ISDN Channel.
LCP UP indicates that PPP negotiation is taking place. If the negotiation is
successful the ISDN Channel is connected to a Remote Node, otherwise the
connection is Down. Idle, Dial and Answering refer to the status of the ISDN
channel.
Speed Shows the current connecting speed.
Menu 24.1 - System Maintenance - Status 09:59:41
Fri. May. 28, 1999
ISDN
--
--
--
--
Chan
--
--
--
--
Status
Down
Down
Down
Down Speed
0kbps
0kbps
0kbps
0kbps TxPkts
0
0
0
0
RxPkts
0
0
0
0
Errors
0
0
0
0
CLU
0%
0%
0%
0%
ALU
0%
0%
0%
0%
Up Time
0:00:00
0:00:00
0.00.00
0.00.00
ISDN Chan Own IP Own CLID Peer IP Peer CLID
-- --
-- --
-- --
-- --
Total Outcall Time: 0:00:00 CPU Load = 7.92%
Press Command:
COMMANDS: 1-Drop ISDN_1 B1 2-Drop ISDN_1 B2 3-Drop ISDN_2 B1 4-Drop ISDN_2 B2
5-Reset Counters 6-Drop All 9-Toggle Status ESC-Exit
