Prestige 480 ISDN Router
11-2 System Maintenance
11.1 System Status
The first selection, System Status, gives you information on the version of your system firmware
and the status and statistics of the ports, as shown next. System Status is a tool that can be used to
monitor your Prestige. Specifically, it gives you information on your system software version,
ISDN telephone line status, number of packets sent and number of packets received.
To get to the System Status, select number 24 to go to Menu 24 - System Maintenance. From this
menu, select number 1, System Status. There are eight commands in Menu 24.1 - System
Maintenance - Status. Entering 1 disconnects the B1 channel call of ISDN line 1; 2 disconnects
the B2 channel call of ISDN line 1; 3 disconnects the B1 channel call of ISDN line 2; 4 disconnects
the B2 channel call of ISDN line 2; 5 resets the counters, 6 drops both B1 and B2 channels of both
ISDN lines; 9 toggles the status and ESC takes you back to the previous screen.
Figure 11-2 Menu 24.1 - System Maintenance – Status
Menu 24.1 - System Maintenance - Status 09:59:41
Thu. JAN. 11, 2001
ISDN
--
--
--
--
Chan
--
--
--
--
Status
Down
Down
Down
Down
Speed
0Kbps
0Kpbs
0Kbps
0Kbps TxPkts
0
0
0
0
RxPkts
0
0
0
0
Errors
0
0
0
0
CLU
0%
0%
0%
0%
ALU
0%
0%
0%
0%
Up Time
0:00:00
0:00:00
0.00.00
0.00.00
Ethernet: Status
Down TxPkts
0
RxPkts
0
Collisions
0
LAN Packet Which Triggered Last Call:
Total Outcall Time: 0:00:00 CPU Load = 3.62%
Press Command:
COMMANDS: 1-Drop ISDN_1 B1 2-Drop ISDN_1 B2 3-Drop ISDN_2 B1 4-Drop ISDN_2 B2
5-Reset Counters 6-Drop All 9-Toggle Status ESC-Exit
