Prestige 480 ISDN Router
System Maintenance 11-5
The following figure shows two examples of triggering packets from the LAN: the first of an
ICMP ping packet (Type: IP) and the second a SAP broadcast packet (Type: Raw). With this
information, you can determine the workstation from the source IP address or the source MAC
address of the packet.
Figure 11-4 LAN Packet That Triggered Last Call
LAN Packet Which Triggered Last Call: (Type IP)
45 00 00 3C 02 12 00 00 3B 01 36 49 00 00 00 00 C0 44 87 22 08 00 62 2B 20 04 00
00 00 08 A9 D0 C0 44 87 22 00 01 02 03 04 05 06 07 08 09 0A 0B
LAN Packet Which Triggered Last Call: (Type Raw)
FF FF 00 22 00 11 00 00 00 00 FF FF FF FF FF FF 04 52 00 00 00 00 00 40 95 90 04
B9 40 08 00 03 02 78 01 A5 A5 A5 A5 A5 A5 A5 A5
Source IP Address
Source MAC Address
