Prestige 480 ISDN Router
5-2 Remote Node TCP/IP Configuration
For the branch office, you need to configure a remote node in order to dial out to the headquarters.
Additionally, you may also need to define static routes if some services reside beyond the
immediate remote LAN.
LAN 1 Setup
Figure 5-2 LAN 1 Setup
LAN 2 Setup
Figure 5-3 LAN 2 Setup
Menu 11.1 - Remote Node Profile
Rem Node Name= LAN_2
Active= Yes
Call Direction= Both
Incoming:
Rem Login= lan2
Rem Password= *******
Rem CLID=
Call Back= No
Outgoing:
My Login= lan1
My Password= ********
Authen= CHAP/PAP
Pri Phone #= 1234
Sec Phone #=
Edit PPP Options= No
Rem IP Addr= 192.168.2.1
Edit IP= No
Telco Option:
Transfer Type= 64K
Allocated Budget(min)=
Period(hr)=
Carrier Acess Code=
Nailed-Up Connection= No
Toll Period(sec)= 0
Session Options:
Edit Filter Sets= No
Idle Timeout(sec)= 100
Enter here to CONFIRM or ESC to CANCEL:
IP address
of the
Prestige on
LAN 2
Menu 11.1 - Remote Node Profile
Rem Node Name= LAN_1
Active= Yes
Call Direction= Both
Incoming:
Rem Login= lan1
Rem Password= *******
Rem CLID=
Call Back= No
Outgoing:
My Login= lan2
My Password= ********
Authen= CHAP/PAP
Pri Phone #= 1234
Sec Phone #=
Edit PPP Options= No
Rem IP Addr= 192.168.1.1
Edit IP= No
Telco Option:
Transfer Type= 64K
Allocated Budget(min)=
Period(hr)=
Carrier Acess Code=
Nailed-Up Connection= No
Toll Period(sec)= 0
Session Options:
Edit Filter Sets= No
Idle Timeout(sec)= 100
Enter here to CONFIRM or ESC to CANCEL:
IP address
of the
Prestige on
LAN 1
