340 Effect Parameter List
23: AUTOPAN [AUTO PAN]
1 L/R Depth L/RDPTH 0,...,127 Left/right depth of panning
2 F/R Depth F/RDPTH 0,...,127 Front/rear depth of panning
3 Pan Direction DIRECTN Auto pan type (L<->R is sine wave, L/R is
square wave)
4 EQ Low Gain LOWGAIN -12,...,+12 Gain with which the EQ will boost/cut the
low range
5 EQ High Gain HI GAIN -12,...,+12 Gain with which the EQ will boost/cut the
high range
24: TREMOLO [TREMOLO]
1 LFO Freq. LFOFREQ 0,...,127 Modulation frequency
2 AM Depth AMDEPTH 0,...,127 Amplitude modulation depth
3 EQ Low Gain LOWGAIN -12,...,+12 Gain with which the EQ will boost/cut the
low range
4 EQ High Gain HI GAIN -12,...,+12 Gain with which the EQ will boost/cut the
high range
5 Input Mode INMODE Mono/stereo selection for the input
25: TRM_BPM [TREMOLO(BPM)]
1 AM Depth AMDEPTH 0,...,127 Amplitude modulation depth
2 PM Depth PMDEPTH 0,...,127 Delay modulation depth
3 LFO Phase Dif. PHASE -180,...,+180 L/R phase difference of the modulation
waveform (no difference at 0 deg (=+000))
4 Input Mode INMODE Mono/stereo selection for the input
5 EQ Low Gain LOWGAIN -12,...,+12 Gain with which the EQ will boost/cut the
low range
26: ROTARY [ROTARY SPEAKER]
1 LFO Freq. LFOFREQ 0,...,127 Rotation frequency of the speaker
2 LFO Depth DEPTH 0,...,127 Depth of modulation produced by speaker
rotation
3 EQ Low Gain LOWGAIN -12,...,+12 Gain with which the EQ will boost/cut the
low range
4 EQ High Gain HI GAIN -12,...,+12 Gain with which the EQ will boost/cut the
high range
5 Dry/Wet Balance DRY/WET Balance of the dry sound and effect sound
L<>R, L>R,
L
L/R
MONO,
STEREO
MONO,
STEREO
D63>W,...,D_W,
...,D
