Effect Parameter List 337
APP
ENDIX
11: ATKLOFI [ATTACK LOFI]
1 Sensitivity SENSITV 0,...,127 Sensitivity
2 Resolution RESOLTN 0, 1/2,...,1/16 Resolution
3 Peak Freq. PEAKFRQ 14,...,54 Frequency at which a peak will be created
in the mid range
4 LPF Cutoff Freq LPF FRQ 34,...,60 Frequency at which the low pass filter will
cut the high range
5 Dry/Wet Balance DRY/WET Balance between dry sound and effect
sound
12: RADIO [RADIO, RADIO, INS, FREE]
1 Mod LPF Freq. MOD LPF 0,...,52 Frequency at which the low pass filter will
cut the high range
2 Mod LPF Reso. MOD LPFQ 10,...,120 Resonance of low pass filter
3 HPF Cutoff Freq HPF FRQ 0,...,52 Frequency at which the high pass filter will
cut the low range
4 LPF Cutoff Freq LPF FRQ 34,...,60 Frequency at which the low pass filter will
cut the high range
5 Dry/Wet Balance DRY/WET Balance between dry sound and effect
sound
13: TURNTBL [DIGITAL TURNTABLE]
1 Noise Level NOISLVL 0,...,127 Noise level
2 Noise Tone NS TONE 0,...,6 Tone of noise
3 Noise LPF Q NSLPF Q 10,...,120 Low pass filter resonance
4 Click Level CLICK 0,...,127 Level of the click sounds
5 Dry Send to Noise DRY NOIS 0,..,127 Mixture of dry signal into the noise
14: DIST [DISTORTION]
1 Drive DRIVE 0,...,127 Degree of distortion
2 LPF Cutoff LPF FRQ 34,...,60 Frequency at which the filter will cut the
high range
3 EQ Mid Freq. MIDFREQ 14,...,54 Frequency at which the EQ will boost/cut
the mid range
4 Output Level OUT LVL 0,...,127 Output level
5 Dry/Wet Balance DRY WET Balance between the dry sound and the ef-
fect sound
D63>W,...,D_W,
...,D
D63>W,...,D_W,
...,D
D63>W,...,D_W,
...,D
